SUP-LWGY Turbine flowmeter thread connection

SUP-LWGY series liquid turbine flowmeter is a kind of speed instrument, which has the advantages of high accuracy, good repeatability, simple structure, small pressure loss and convenient maintenance. It is used to measure the volume flow of low viscosity liquid in closed pipe. Threaded type, simple to install and maintain, usually used for small diameter flow measurements: Male:DN4~DN100; female:DN15~DN50

Characteristics

Pipe diameter: DN4~DN100

Accuracy: 0.2%  0.5%  1.0%

Power supply:  3.6V lithium battery; 12VDC; 24VDC

Ingress protection: IP65

Inquiry
Email us
turbine flowmeter thread connection
turbine flowmeters
liquid turbine flowmeter
DN4~DN100 turbine flowmeter
turbine flowmeter clamp on type
turbine flowmeter thread connection
turbine flowmeters
liquid turbine flowmeter
DN4~DN100 turbine flowmeter
turbine flowmeter clamp on type

  • Specification

 Product  Turbine flowmeter
 Model  SUP-LWGY
 Diameter Nominal  DN4~DN100
 Nominal Pressure  6.3 MPa
 Accuracy  0.5%R, 1.0%R
 Medium viscosity  Less than 5×10-6m2/s
 for the liquid with >5×10-6m2/s,
 the flowermeter needs to be calibrated before using
 Medium Temperature  -20℃～＋120℃
 Power Supply  3.6V lithium battery; 12V DC; 24VDC
 Output Signal  Pulse, 4-20mA, RS485, Modbus
 Ingress protection  IP65



  • Introduction

SUP-LWGY series liquid turbine flowmeter is a kind of speed instrument, which has the advantages of high accuracy, good repeatability, simple structure, small pressure loss and convenient maintenance. It is used to measure the volume flow of low viscosity liquid in closed pipe.

thread turbine flowmeter

  • Application

digital turbine flow meter

turbo flow meter

turbine type flow meter

  • Description

turbine flowmeter impeller supplier

turbine flowmeter transmitter
